Metal Seated Tilting Disc Check Valves
"Our Metal Seated Tilting Disc Check Valves are designed in accordance with EN /ISO standards and to meet the high Quality requirements."
Metal Seated Tilting Disc Check Valves are designed in accordance with EN /ISO standards and to meet the high Quality requirements. The valves are offered with slanted seat construction to prevent the reverse flow and hydraulic damper will reduce the risk of water hammer.
Specifications
Size range: DN250 to DN1400
Working Pressure: 10 bar & 16 bar
Standards Compliance
Flange Connection: EN 1092-2
Design & Manufacture: EN 1074
Face to Face: EN 558
Models
VCT14: Face to Face as per EN 558 / ISO 5752 Series 14
Testing: EN 12266-1 & 2
Seat Test: 1.1 x PN
Body Test: 1.5 x PN
Coating: Fusion Bond non-toxic Epoxy WRAS, Coated as per DIN 30677-2
Materials
Body: Ductile Iron EN-GJS-500-7
Disc: Ductile Iron EN-GJS-500-7
Shaft: Stainless Steel / Duplex
Bush: Bronze + PTFE /SS316 + PTFE
